Pusa Totinilima Falesu'esu'e

Auaunaga Lautele

O le -lua falesuesue pusa totigilima e fa'aleleia atili ai le gaosiga e ala i le fa'agaioia o le fa'agasologa tutusa o vaega maa a'o fa'atumauina pea le si'osi'omaga mago (< 1 ppm H₂O/O₂) for laboratory lithium ion battery & sodium ion battery production. Its ergonomic layout features shared ancillary tools (e.g., heat sealers, crimpers) accessible from both stations, reducing redundant movements and accelerating cell assembly. Designed for continuous operation, the system includes integrated monitoring sensors, automated regeneration, and large airlocks for material transfer. Ideal for high-throughput research labs, it supports simultaneous preparation of trial batches (e.g., different electrolytes or formulations) under identical atmospheric conditions, ensuring reproducibility and reducing experimental turnaround time.

Fa'amatalaga fa'apitoa

1) Pusa Totinilima

2) Antechamber Tele

• Fale fesuia'i

Fua: lautele 360mm, umi 600mm Mea:
304 u'amea u'amea Mata:
o totonu e pulumu, ma fafo e vali (pa'epa'e)

• Mea fa'aoga

Fata fa'ase'e: 304 u'amea uamea faitoto'a o le fale: faitoto'a fa'alua, mea fa'amea alumini,
mafiafia 10mm, fa'agaioiga tu'usa'o, fa'atasi ai ma masini si'i
Fua o le mamafa: fa'aaliga analog

• Pulea Solenoid valve

pa'i mata otometi galuega

3) Laiti Antechamber

• Fale fesuia'i

O le tele e 150mm le lautele, 300mm le umi, ma le umi o le vaega e ulu atu i totonu o le pusa e 100mm
Mea: 304 u'amea u'amea
Lau'ele'ele: o le pito i totonu e pulumu, ma le pito i fafo e valiina (pa'epa'e)

• Mea fa'aoga

Faitotoa o le fale: faitoto'a ta'ilua ma ipu fa'ase'e fe'avea'i, oomi -fa'amau auala tatala Fua oona: fa'aaliga fa'atusa.

• Pulea

Fa'agaioiga tusi lesona valve

4) Fa'amama kasa faiga fa'asalalau

• Fa'amamāina koluma

Galuega: ea malulu, aveese vai ma deoxygenation
Mea fa'apipi'i: 304 u'amea fa'amama mea fa'amama: fa'aputu kopa: 5 kilokalama; sieve mole: 5 kilokalama malosi mama:
deoxygenation: 60L; fa'afefeteina: 2Kg,
Suavai ma le okesene faasinoupu: itiiti ifo i le 1ppm

• Fa'atonuga o le ta'amiloga kesi galue: nitrogen, argon Malosiaga ta'amilosaga: 90m3/h
• Toe Fa'afouina Fa'agaoioiga: PLC e fa'atonuina le fa'agasologa o le toe fa'afouina Fa'afouga kesi: kasa fefiloi o le kesi galue ma le hydrogen, (hydrogen 5-10%)
• Pumu mama Fa'amatalaga: 12m3/h, pamu vane rotary, fa'atasi ai ma le suau'u suau'u faamama, fa'atonutonu le vibration o le ea.
• Valve Valve Autu: DN 40 KF, valve tulimanu eletise Pulea valve: solenoid valve integrated

5) Pulea faiga: galuega

• Puleaina o le mamafa: O le mamafa galue o le pusa pule ma le potu fesuia'i e mafai ona tu'u sa'oloto i totonu o le +/- 10mbar, ma o le a otometi lava ona puipuia e le faiga pe a sili atu i le +/- 15mbar;
• Otometi pamu ma molia: O le potu tele suiga e otometi lava ona pamu le gaogao ma toe faʻatumu le ea i le tasi faʻamau.
• Fa'amama otometi: Tasi-ki e suitulaga otometi ma fa'amamāina le siosiomaga i totonu o le kapeneta.
• Fa'ailo fa'afuase'i: e mafai ona seti le tau fa'ailo vai ma le okesene, pe a sili atu le okesene vai i le tau fa'atulagaina, o le a fa'aoso le fa'ailo fa'afuase'i.
• Lapataiga a le System: E tupu se mea sese i le faʻaogaina o le polokalama, ma faʻaalia se feʻau sese poʻo se lapataiga.
• Su'esu'eina le fua o le lepa: Fa'atasi ai ma le okesene-o le auala e maua ai ma le ala fa'amalosi e su'esu'eina le fua o le tafega, e mafai ona otometi lava ona iloa le liko o le kapeneta e puipuia ai le lepa o mea leaga.
• Fa'amaumauga Fa'amaumauga: Fa'amaumau fa'amaumau le vai ma le okesene fa'amaumauga o le fa'agaioiina o meafaigaluega ma fa'aali fa'amaumauga fa'asolopito
• Puipuiga Pusa: A itiiti ifo le mamafa o le pusa nai lo le tau faʻatulagaina, o le a otometi lava ona tapunia le potu suiga tele e tuʻuina atu le ea e puipuia ai le faʻaleagaina o le mamafa mai le faʻaleagaina o le pusa totigilima.
• Foot pedal: Pulea le mamafa o le tino pusa, faigofie e faʻaogaina le faʻateleina o le mamafa ma faʻaitiitia
• Fuafuaga o polokalame fa'akomepiuta: Ua fa'apipi'iina le PLC i le fa'avasegaina o polokalame fa'akomepiuta, lea e mafai ona fa'atinoina galuega e pei o le fa'atatauina o le mamafa o le mole, vaila'au vaila'au fa'ainisinia, ma le calculator.
• O isi galuega: e aofia ai -su'esu'ega a le tagata lava ia, fa'amalo-pa'u ma uiga amata-, fa'atasi ai ma le fa'atonutonuina o le mamafa ma galuega fa'afetaui; pulea otometi, pulea taamilosaga, puipuiga upu faataga.

6) Fa'aaliga faiga:
Siemens PLC touch screen smart 700 o loʻo faʻaaogaina e faʻaalia ai tulaga faʻaogaina, faʻamalosi o le kapeneta, faʻamaumauga faʻamaumauga, ma isi.

7) Puleaina o le masini masini
British EDWARDS vacuum pump, lea e mafai ona amata ma le lima poʻo le PLC, faʻatasi ai ma le tafe o le 12m3 / h, lea e mafai ona faʻamama le potu suiga ma tausia le paleni mamafa o le tane. Ole fa'ato'a gaogao ole pamu vacuum e itiiti ifo pe tutusa ile 2x10-1pa.

8) Okesene Sensor
Fua fuaina: 0-1000ppm
Electrochemical Fuel Cell Oxygen Analyzer, sa'o o le 0.2 ppm, fetaui ma solvents, ma leai se tausiga-
9) Susū susū
Fua fuaina: 0-1000ppm
E i ai le tele o faʻaoga, aemaise lava mo tagata faʻaoga e pei o le gaosiga o le maa lithium ma le uʻamea uʻamea
10) Organic solvent adsorber
Tele: tuu i totonu o le pusa,
tele: faʻatumu i le 10kg molecular sieve, e mafai ona vave faʻafouina le meafaitino, ma e le faʻaleagaina ai le siosiomaga mama maualuga.
11) Ea malulu fa'apisinisi
O lo'o tu'u se ea malulu fa'apisinisi i le pito i luga ole pusa totigilima. Ole fua fa'atatau ole pusaaisa e 1050W; vevela fetu'una'iga va'aiga:15-36 tikeri, 220V/50Hz, Input mana:650W, tele: (L * W * H) 580*560*400, mamafa: 48kg.

Ta'iala e talia:

I lalo o tulaga masani, o lona uiga, o le vevela tumau o le 20 tikeri, o le mamafa o le ea masani, o se puna kesi inert o le 99.999%, ma se pusa gaogao gaogao, o le vai ma le okesene faasino igoa e itiiti ifo i le 1 ppm.
